draughtproofing the bottom of a door.

[plasticpigeon]

My house has subsided quite a bit and when the floor was leveled I had to cut a considerable amount off the bottom of my back door to get it to clear the floor. However now the lower bolt is closer to the bottom of the door and I can't put a brush strip under the bolt. What do people think of putting a brush seal on the outside of the door, or perhaps making a raised threshold that the bottom of the door can butt up against.



[Me!]

Does the door open into the house or out please?



[Feltwell]

I'd make a threshold and incorporate a brush seal personally.

Alternatively, if you didn't want to do that, could you machine a brush pile carrier into the bottom of the door? Reddiseals sell them.



[plasticpigeon]

It opens into the house unfortunately.



[plasticpigeon]

Machining a brush seal into the bottom is the high effort high quality option.



[88v8]

Hardwood threshold.

And expanding tape stuck to the threshold
http://affixit.co.uk/index.php?main_page=advanced_search_result&search_in_description=1&zenid=f29baa6ad7102bf8004caa49930f45da&keyword=expanding&x=27&y=12

Working well for me on our very wonky west door.

Ivor



[plasticpigeon]

Hi Ivor, is that tape to stick the threshold to the step?



[Feltwell]

My front door sits very close to the floor like that. Drives me mad - any little bit of grit on the floor and it catches it. You can't have a door mat either. Fitting a threshold so I machine a bit off the bottom of the door is on the very long list of jobs to do to this place..........

I'd do it properly and fit a threshold, then you can at least have a doormat to stop muck coming in from your garden.



[88v8]

Hi Ivor, is that tape to stick the threshold to the step?

No, it sticks to the edge of the threshold and the door closes against it to provide a seal. The tape has excellent conformity to uneven gaps.

Presumably the door has a water bar on the outside? Would then be better to stick the tape to the door rather than the threshold, so the tape won't get walked on.

Ivor



[plasticpigeon]

No, it doesn't have a water bar, just the kitchen floor running into a blue brick step.



[MatthewC]

Whatever way you do it, I think it's essential that you do. I fitted one on the internal door in the small utility room, and was amazed at how much warmer it made the next room inside - wished I'd done it a year before!



[88v8]

No, it doesn't have a water bar, just the kitchen floor running into a blue brick step.

It will need a water bar on, or the rain will trap between the door and the threshold.
Another job....

Ivor



[plasticpigeon]

Would this be the kind of arrangement that you describe, but with a sold threshold that the door butts up against?



[Delta]

It may not work depending on your door and door step/threshold, but I think the default approach is to have a water bar set into the threshold that the door closes against. See Figure 6.5 http://books.google.co.uk/books?id=...108#v=onepage&q=water bar rebate door&f=false.

This is what I have for both my back and front door.
